Inrush Rating: 0.25 sec (10 repeats) | 1,500 Amperes DC |
Cranking Rating: 9.75 sec (10 repeats) | 700 Amperes DC |
Intermittent Rating: 5 min (UL 1107) | 525 Amperes DC |
Continuous Rating: (UL 1107) | 350 Amperes DC |
Maximum Voltage Rating | 32 Volts DC |
Terminal Stud Size | 3/8"-16 (M10) |
Terminal Stud Torque | 140 in-lb (15.82 N?m) |
Cable Size to Meet Ratings | 4/0 AWG (95mm²) |
Cable Clearance For 4/0 AWG Cables | 1.10" (27.9mm) |
Case Material | Reinforced Polycarbonate |
