Xantrex Freedom EX4000 4000W Marine Inverter Charger 48VDC In 120VAC Out

Click to enlarge

Details:

Xantrex Freedom EX 4000 Inverter/Charger with 48VDC-to-12VDC Converter

Model: 820-4080-41

Stack up to 3 units in parallel; up to 2 units in series
48VDC to 12VDC converter output
Highly configurable charger specifically designed for lithium ion batteries
Built-in 50A Transfer Relay
Extended Surge Rating to 2X continuous power for 5 seconds
True Sine Wave AC Power
Ignition Control Feature to turn inverter on/off via a 12VDC signal

The new FREEDOM EX 4000 is a truly unique, true sine wave power solution packing a powerful 48VDC, 4000W (8000W [5s]) inverter, 80A 48VDC battery charger, 50A transfer relay and a 48VDC to 12VDC, 45A converter inside one box. Designed for mobile applications that utilize 48VDC battery systems, the FREEDOM EX 4000 is designed to work as a standalone AC and DC power solution or supplement an existing generator to create a hybrid system. The FREEDOM EX 4000 features the most widely used communication protocols — RV-C (RV), enabling it to be used in virtually any application that requires integration with 3rd party MFPs and software.

Specifications

ELECTRICAL SPECS - INVERTER
AC Output Operating Voltage Options	105 - 130VAC
Continuous Output Power	Continuous Power 4000 W @40 C True sine wave (TSW) at 120Vac
Continuous AC Output Current	33A
Surge Power	8000W(5 sec)
Frequency	60Hz
ELECTRICAL SPECS - BATTERY CHARGER
Nominal DC Output Voltage	48VDC
Charger Voltage Range	40 - 64VDC
Maximum DC Output Current (user configurable down to 5 A)	80A
Supported Battery Types	Flooded, Gel, AGM, Lithium Ion, Custom
ELECTRICAL SPECS - PASS-THROUGH
AC Input Voltage:
Single-phase (L1 - N and L2 - N)	80 - 138Vac
Split-phase* (L1 - L2)	160 - 276Vac
Frequency (input/output)	60Hz
Continuous AC current (input/output)	40A
ELECTRICAL SPECS - 12 VDC POWER SUPPLY
Nominal DC Output Voltage (fully regulated)	13.5VDC
Maximum DC Output Current	45ADC continuous (at 77 F (25 C) ambient)
Typical Application* Powering	12 VDC Loads
ELECTRICAL SPECS - COMMUNICATIONS SUPPORTED
Recreational Vehicles (RV)	RV-C Protocol
Trucking Vehicles (future offering)	J-1939 Protocol
Marine Vessels (future offering)	NMEA-2000 Protocol
GENERAL SPECS
Operating Temperature Range	14 to 140 F (-10 to 60 C), with output derated above 104 F (40°C)
Storage Temperature Range	-40 to 158 F (-40 to 70 C)
Operating Humidity Range	5 to 95% RH, non-condensing
Transfer Relay AC Current Rating	50A (40A continuous)
L x W x H	17.1in (434mm) x 14in (354mm) x 8.1in (205mm)
Net Weight	79.4lbs (36.0kg)

What's in the Box:

Freedom EX 4000
Installation guide
pair of ½" bushings
pair of ¾" bushings
one network terminator

Did you Know?

ALL products we sell are factory new and come with the full Manufacturers Warranty!

Related Accessories:

Item #	Description	Price	Order
XAN808-0817-03	Xantrex Freedom Ex 4000 Remote Panel	$75.99
