Phase Three “Smart” battery charging technology is now
available in a wide range of power levels, allowing you to select the right
size, features and flexibility you require for virtually any application from
small recreational craft to large live-aboards, workboats and other commercial
vessels. These chargers interact with batteries to put them through the optimum
three stage charge process which provides for fastest recovery and ideal
conditioning, maximizing battery performance and extending battery life.
A selector switch adjusts output voltage to adapt for
gel-cell/flooded lead-acid/AGM battery types. An optional temperature
compensation sensor also adjusts output for ideal voltage based on changes in
the batteries' ambient temperature. All models are housed in a rugged stainless
steel case with a durable white powder coat finish, and the internal circuitry
is polyurethane coated for maximum corrosion resistance.
Features
• “Smart” circuitry provides three stage charging—bulk, absorption, float.
• Wide model range covers battery system ratings from 14-950 amp-hours
• Gel-Cell/Flooded Lead-acid/AGM battery type switch selects optimum
charge/float voltages.
• Multiple isolated output banks; ammeter indicates total output current.
(except PT-7)
• Optional sensor adjusts output voltage based on battery temperature. (except
PT-7)
• Current limiting-prevents damage from overloading.
• Charger status clearly displayed with L.E.D. and/or audible indicators or
optional remote panel.
• Use as a power supply; can power loads without a battery in line.
• Built to last—rugged stainless steel case with a durable white powder coat
finish with an optional
drip shield and marinized internal circuitry.
12 Volt Models |
PT-25W |
Input Amps At Full Load |
|
At 115 VAC |
6.5 |
At 230 VAC |
4 |
P.F. Rating |
.7 |
Max Output Amps |
25 |
Output Banks |
3 |
Battery Capacity (Amp-Hours) |
25-250 |
Operating Temp. Rating Reference |
14°F - 140°F |
Case Size Ref. (H x W x D) |
12.5" x 7.7" x 4.3" |
Weight (lbs) |
8.2lbs |
Optional Temp. Sensor Modle |
RP |
Equalize Option |
Yes |
Output Indicator Ref. |
Total output ammeter and charger status L.E.D.'s/Alarms |
Compliance Ref |
USCG CFR 183.410 (Ignition protected) |
Input VAC (50-60 Hz.) |
90-132 or 180-264 |
|
|
