Internal elevation mechanism provides pitch control of spotlight beam; protects elevation mechanism from weather
Includes fingertip remote control Point Pad™ up to three remote Point Pad™ units may be installed on system; surface/flush mount options included
Rugged triple-primed and sealed, marine grade aluminum housing
XRCiZ™ feature rotates and moves light assembly every 30 days from activation to keep all bearing surfaces free of corrosion and all electrical contacts functional (can be disabled)
Salt water-resistant construction with nylon and phenolic washers, aluminized stainless steel screws with insulating lubricant
Wiring harness included
Size: 12 x 13 x 9.3 in (31 x 33 x 23.5 cm)
Weight: 31 lbs (14.06 kg)
Material: Cast Aluminum, Tempered Glass
Input Voltage: 12V-24VDC
Color: White
Operation: Remote Controlled Point PadT
Beam Spread: 6ø
Elevation Angle: 15ø Up, 30ø Down
Rotation: 360ø Continuous
Rotation Speed: Fast 30ø per Second, Slow 10ø per Second
Elevation Speed: 3ø per Second
Lamp: Twin 35W Metal Halide Lamps 1,000 Hours Operating Life
Accessories: Secondary Point Pad™ for Remote Control with Install Kit (P/N 9282.3) Replacement 35W Halide Lamps
Footprint Diameter: 9 in (23cm)
Limited Warranty: 1 Year
Carton Dimensions: 20.5" x 14.25" x 19.25"
Carton Weight: 40 lbs
Units per Carton: 1
|
