The new standard of powerful electric outboards
We developed our new Cruise R series for boats, which are controlled with
remote steering and remote throttle, as well as for sailboats steered with a
rudder.
Our Cruise R models come with substantial improvements: The fact that we
already supplied the best overall efficiency on the market didnīt stop us from
going even further. Our new models achieve efficiency rates of 51 %, which means
over half of the energy supplied by the batteries is transformed into propulsive
power (measured after all losses, including propeller losses). In addition, we
have made the motor even more robust.
The Cruise R can stand even a temporary complete submersion under water without
taking any harm. Also, we have integrated a GPS receiver and an information
system, so you always know how much battery power and remaining range you have.
Finally, we made the motor even more powerful. The Cruise 4.0 R has the
propulsive power of an 8 horsepower combustion engine in displacement drive and
the thrust power of a 9.9 hp outboard motor.
| |
Cruise
2.0 S |
Cruise
2.0 L |
| Input
power in watts |
2,000 |
4,000 |
| Rated
voltage in volts |
24 |
48 |
|
Propulsive power in watts |
1020 |
2040 |
|
Comparable gas outboards (propulsive power) |
5 hp |
8 hp |
|
Comparable gas outboards (thrust power) |
6 hp |
9.9 hp |
| Maximum
overall efficiency in % |
51 |
51 |
| Static
thrust in lbs |
110 |
214 |
| Total
weight in lbs |
37.5 |
39.7 |
| Shaft
length in inches |
24.6 |
24.6 |
|
Integrated battery |
no |
no |
| Propeller
dimensions in inches |
12 x 10 |
12 x 10 |
| Propeller
speed at full power in rpm |
max.
1,250 |
max.
1,250 |
| Control |
Remote
throttle control |
Remote
throttle control |
| Steering |
Provision
for connection to standard remote steering; lockable |
Provision
for connection to standard remote steering; lockable |
| Tilting
device |
Manual
with grounding protection |
Manual
with grounding protection |
| Trim
device |
manual,
4-step |
manual,
4-step |
| Stepless
drive forwards/reverse |
yes |
yes |
Example of Range:
Cruise 2.0 R (with 2 x 12 V / 200 Ah lead batteries), 30 square-metre
skerry cruiser 40ft, 2.6 tons
| Examples of use |
Speed in knots |
Range in nm |
Run-time in hours |
| Full throttle |
5.0 |
10.0 |
2:00 |
| Half throttle |
2.7 |
44.6 |
16:30 |
| Slow speed |
1.5 |
165.0 |
110:00 |
Cruise 4.0 R (with 4 x 12 V / 200 Ah lead batteries), 30 square-metre
skerry cruiser 40ft, 2.6 tons
| Examples of use |
Speed in knots |
Range in nm |
Run-time in hours |
| Full throttle |
6.3 |
12.6 |
2:00 |
| Half throttle |
5.0 |
20.0 |
4:00 |
| Slow speed |
2.7 |
89.1 |
33:00 |
