Specifications
|
|
|
General
|
|
|
Number of Features
|
All: U.S.A., Canadian, International 10
NOAA Weather Channels
|
|
Channel Spacing
|
25 kHz
|
|
Modulation
|
5 kHz Max.
|
|
Input Voltage
|
13.8 VDC
|
|
Current Drain:
Stand-by
Receive
Transmit
|
200 mA
300 mA
5 A @ High Power
1 A @ Low Power
|
|
Temperature Range
|
-20°C to 60°C
|
|
Unit Dimensions
|
6.25" x 2.25" x 7.125"
(159mm x 57mm x 180mm)
|
|
Unit Weight (Lbs)
|
2 lbs., 6.8 oz. (1100g)
|
|
Receiver
|
|
|
Frequency Range
|
156.050 to 163.275 MHz
|
|
Receiver Type
|
Double Conversion Super-Heterodyne
|
|
Sensitivity:
20 dB Quieting
12 dB Sinad
|
0.35uV
0.30 uV
|
|
Adjacent Channel Selectivity
|
-60 dB
|
|
Intermodulation and Rejection
|
-60 dB
|
|
Spurious & Image Rejection
|
-60 dB
|
|
AF Output
|
4 Watts @ 8 Ohms
|
|
Transmiter
|
|
|
Frequency Range
|
156.025 to 157.425 MHz
|
|
RF Output Power
|
1 or 25 Watts
|
|
Spurious Emissions
|
-60 dB @ High Power
-55 dB @ Low Power
|
|
Microphone Type
|
Electret
|
|
Microphone Impedance
|
2000 Ohms
|
|
Frequency Stability
|
+/- 10 ppm
|
|
FM Hum & Noise
|
40 dB
|
|
Features
|
Benefits
|
|
1 or 25 Watts
|
Dual output power for short and long
communication.
|
|
U.S.A., Canada & International Channels
|
Allows operation on any of the three (3)
different channel maps established for these areas.
|
|
10 NOAA Weather Channels
|
Instant access to national all hazards
and weather information, 24 hours a day.
|
|
Weather Alert
|
Alerts with an audible tone and visual
alarm if threatening weather is nearby.
|
|
Instant Channel 16/9
|
Instant access to channel 16 and channel
9 for emergency situations.
|
|
DSC (Digital Selective Calling)
|
Meets internationally recognized
requirements for RTCM- SC-101 Digital Selective Calling that allows
you to send a distress signal at the touch of a button or exchange
position information with other boats or stations.
|
|
GPS Capability
|
When connected to a Cobra or most other
GPS receivers, you can send your position to other boats in an
emergency, or exchange position information with other boats or
stations.
|
|
Dual Watch
|
|
|
Scan
|
Scan all channels to find conversations
in progress.
|
|
Signal Strength Meter
|
Shows the strength of incoming signal.
|
|
3 Year Warranty (on radio)
|
For products sold in the U.S.A.
|
|
Illuminated Function Keys
|
Allows high visibility of function keys.
|
|
Illuminated LCD Display: Large
|
Allows high visibility of display.
|
|
Noise Canceling Microphone with Controls
|
Blocks background noise. Controls allow
instant access to channels 16 & 9 and changing of channels & setting
features.
|
|
External Speaker Jack
|
Allows connection of an external speaker
(not included).
|
|
Submersible
|
Meets JIS7 standards; Submersible for 30
minutes in one meter deep water.
|
