  Mastervolt 81400100 DC Master 24/12-3A 24-32VDC To 13.6 Vdc - 3A
Click to enlarge

Mastervolt 81400100 DC Master 24/12-3A 24-32VDC To 13.6 Vdc - 3A

Item #: MVT81400100



Quantity:

23%

List Price:

$56.65

Regular Price:

$44.99

Sale Price:

$43.64



Usually ships the next business day.
No restocking fees on return.

Click to verify BBB accreditation and to see a BBB report.

Details:

Thanksgiving Sale! Save until November 27th or while supplies last!

Mastervolt DC master 24/12-3A DC-DC Converter, Non-Isolated

Model: 81400100
  • Recreational and semi-professional use.
  • Easy to install using included mounting bracket, screws and fasteners.
  • Smart electronics mean no unnecessary heat generation.
  • Continuous output.
  • Two minutes of extra power for short power boosts.
Specifications
General Specifications
Nominal output voltage13.6 V
Max. output power82W
Nominal output power41W
Max. output current (for 2 min. intervals)6A
Continuous output current3A
Nominal input voltage24V
Input voltage range20-32V
Galvanic isolationNo
StabilisedYes
ApprovalsCE, E-mark
Technical Specification
DC consumption< 10 mA
ConnectionsFast-on
Temperature range (ambient temp.)-13 °F to 176 °F
Sound level< 30 dBA at 1 mtr
Protection degreeIP53
CoolingNatural cooling
Dimensions2.6 x 3.4 x 2.0 inch

What's in the Box:
  • DC Master 24/12-3A Non isolated
  • Mounting bracket with fastenrs
  • Documentation
