Features

Display:


• 5" (12.7 cm) diagonal screen
• Film SuperTwist LCD
• High-definition 480x480 resolution
• Amber LED backlit screen and keypad
• 16-level grayscale

• Digitally record/play sonar graphs and GPS trip details with optional, reusable compact Multi-Media Cards (MMC) or Secure Digital (SD) memory cards. One waterproof slot for instantly-expandable memory using a single 8MB-512MB card
• Depth capability to 800 ft* (244 m) with 1500 watts of peak-to-peak power
• High-performance, low-profile 200 kHz Skimmer« transducer with built-in temp sensor delivers up to 60¦ of fish detection area with high sensitivity settings - Operates at boat speeds up to 70 mph (61 kts)
• Trolling speed and distance log readings available with purchase of an optional sensor
• FishReveal feature exposes fish targets hidden in surface clutter, weed beds, thermoclines, and other types of underwater cover
• HyperScroll feature locates and displays fish targets at higher boat speeds


• Advanced Signal Processing (ASP) automatically adjusts your settings for the best sonar picture
• Patented GRAYLINE« separates fish from nearby structure and bottom
• Advanced Fish I.D. shows underwater targets in different sizes of fish symbols
• FishTrack displays target depth readings above fish symbols
• Surface water temperature readings come from a built-in temp sensor in the transducer
• Zoom with zoom bottom tracking and easy zoom-in/out control
• Selective on/off sonar alarms: Shallow, Deep, Fish and Zone

• 12-parallel channel GPS reception with fast, strong satellite lock-ons, precise tracking, and position updates every second
• Selectable on/off WAAS reception for enhanced position accuracy to 3 m (under 10 ft) at select locations
• All-new, built-in Eagle« background map with enhanced continental U.S. and Hawaii detail including nav aids
• High-speed map screen updates
• Optional GPS Mapping Accessories Pack with MapCreate CD software that:
  • Lets you create unlimited, custom, detailed maps on MMC or SD memory cards
  • Includes unique, searchable database of streets, addresses, and over 700,000 Point-of-Interest (POI) to easily find/identify marinas, restaurants, airports, emergency services, and more
• Saves up to 1,000 waypoints, 1,000 event markers, and 100 routes (up to 100 waypoints/route)
• 100 savable plot trails with up to 10,000 points per trail
• 42 graphic icons to mark your favorite spots
• 37 map zoom ranges - from 0.05 to 4,000 miles - with easy zoom-in/out control
• Compatible with optional Navionics« CLASSIC, GOLD, and HotSpots electronic charts on MMC cards

• Internal back-up memory keeps stored GPS data and sonar settings safe and accessible for years
• Completely sealed and waterproof, even for use in harsh saltwater environments
• Full one-year warranty

Availability: Usually ships the next business day.

EAG117-10
